- Page 1 User Manual Cellspin II Clinical Centrifuge Date of Purchase Serial No. Place of purchase...
- Page 2 Clinical Centrifuge Cellspin II Copyright ⓒ 2020 Hanil Scientific Inc. All rights reserved. Contact Us If you have and questions, contact Hanil Scientific Inc. or place of purchase. +82-2-3452-8966 Order, Inquiry: sales@ihanil.com Tech. support: techsupport@ihanil.com The contents in this operating manual are subject to change for device improvement.
-
Page 3: Table Of Contents
CONTENTS General Considerations------------------------------------------------- Safety Transport & Storage Safety label Electric safety information Product description----------------------------------------------------- Appearance -5 Components -5 2.3 Technical specifications -6 Installation ---------------------------------------------------------------- Packing Inspection Installation -7 3.2.1 Selecting the location -7 3.2.2 Power connetion -8 Operation ---------------------------------------------------------------- Control panel 4.2 Opening and closing the lid -10 4.3 Loading and removal of the rotor -10 4.4 Loading cytocell... -
Page 4: General Considerations
2. Check the voltage to be used, before connecting the centrifuge to the power source. 3. Only use rotors, parts, and accessories provided by Hanil Scientific Inc. Hanil Scientific Inc. is not responsible for damages of the device and accidents caused by using parts and accessories not recommended. -
Page 5: Transport & Storage -4
1. General Considerations 1.2 Transport & Storage • Only lift and transport the • The device and the accessories device with sufficient number of may only be stored in dry rooms helpers. -Storage- -Transport- Ambient temperature 5℃~35℃ Ambient temperature -10℃~40℃ Maximum relative humidity 30%~85% Maximum relative humidity 10%~90% Air pressure 500~1060hpa... -
Page 6: Product Description
2. Product description 2.1 Appearance ② ③ ① ④ ① Control panel ② Lid window ③ Centrifuge Lid ④ Power switch 2.2 Components ① Cellspin II ② Rotor: A-cyto-12 ③ User manual ④ Emergency Door Tool 5 l www.ihanil.com... -
Page 7: Technical Specifications -6
2. Product description 2.3 Technical Specifications Max. RPM 3,000 rpm Max. RCF 1,175 xg Max. Capacity 12 slides x 0.5~0.6 mL Time control < 100 min or continuous Program memory Dimension (W x D x H, mm) 318 x 436 x 260 Weight without rotor 23kg Power requirement (VA) -
Page 8: Installation
3. Installation 3.1 Packing Inspection •Check packing conditions carefully, before unpacking. •Contact Hanil Scientific Inc. immediately if damages found. •Check the delivery for completeness. •You can get contact details on packing boxes and the back of the manual. 3.2 Installation 3.2.1 Selecting the location... -
Page 9: Installation -7
3. Installation 3.1 Packing Inspection 3.2.2 Power Connection • Connect the device to voltage sources which correspond to the electrical requirements on the label attached to the device. • Use sockets with a protective earth conductor and provided powercord. 1. Plug the cord into the outlet. 2. -
Page 10: Operation
4. Operation 4.1 Control Panel ① ③ ② ④ Button Function To set the speed and for automatic conversion between RPM and RCF Time To set time up to 99 min 59sec (0:00:00: continuous) Soft Start To operate with slower and smoother acceleration / deceleration Stop Open To open the instrument lid... - Page 11 Close the door until you hear the door clank. When the door is opened, the door LED turns on 4.3 Loading and removal of the rotor •Only use rotors, parts, and accessories provided by Hanil Scientific Inc. •Do not use scatched or cracked rotor in use. Loading ①...
-
Page 12: Operation
4. Operation 4.4 Loading Cytocell accessories • Only use tubes and accessories provided or approved by Hanil Scientific Inc. • Always use the same type of tube. • Tubes should be loaded symmetrically. • Do not exceed the maximum rated speed of the tube. -
Page 13: Setting Rpm/Rcf -12
4. Operation 4.5 Setting RPM/RCF [Setting RPM] 1. Press a [RPM/RCF] button once. RPM MODE is on by pressing the [RPM/RCF] button once. 2. Press the [▲▼] buttons to change the set value. Speed setting unit: 10 rpm 3. Press the [RPM/RCF] button again to set the value. [Setting RCF] 1. - Page 14 4. Operation 4.7 Save / Recall a program [Save a program] 1. Set parameters. 2. Keep the [PROG] button pressed over 3 seconds to save your set values. The LED of [PROG] button and SEC/Save are turned on. 3. Input the program number by using the [▲▼] button. Up to 10 programs can be stored.
- Page 15 4. Operation 4.9 Soft start / stop The [SOFT START/STOP] button is used for gentle acceleration and deceleration for sensitive samples. 1. After setting TIME and RPM, press the [SOFT START/STOP] button once. The LED of [SOFT START/STOP] button is on while running. The door is automatically opened when the operation is completed.
-
Page 16: Maintenance
5. Maintenance 5.1 Care instructions • The following procedures should be performed regulary. ①Regularly inspect the rotor chamber for check the motor shaft is nomal. ②Rotate the shaft with your hand to make sure it turns smoothly ③Use the stopwatch to check that the time setting is correct 5.2 Cleaning •... - Page 17 6. Troubleshooting 6.1 General errors Problem Recommended Action Check the power cord connection. Power failure Check the power fuse of the device. Device cannot be started Check the lid is closed completely. Lid cannot be opened Press the ‘Lid open button’. Clean and the door latch and Lid cannot be closed close the lid.
- Page 18 Error 1 * If the error message does not disappear, please contact a Service Engineer of your local Hanil Scientific’s partner. * If the door opens while spinning or has any trouble in the door sensor, this message may come up.
- Page 19 Action Possible Causes * If the installed software have any bugs, this message may come up. * Contact a Service Engineer of your local Hanil Scientific’s partner and get the firmware upgrade. Wire disconnection or tuning of the Error 7...
- Page 20 6. Troubleshooting 6.3 Emergency Lid Open If the device door cannot be opened, you can activte the emergency open manually. 1. Wait for rotor to stop before activating the emergency open. 2. Insert the pin into the emergency open hole and push it until the door is opened. Emergency Door Open Hole 19 l www.ihanil.com...
- Page 21 7. Rotor 7.1 Angle rotors sales@ihanil.com / techsupport@ihanil.com l 20...
- Page 22 Memo...
- Page 23 Memo...
- Page 24 Hanil Scientific Inc. 16 Arayukro, Gimpo 10136, Rep. of KOREA T. +82-2-3452-8965 techsupport@ihanil.com sales@ihanil.com www.ihanil.com...
