IPC962/IPC964 Series User's Manual
out
dx,al
mov
dx,2Fh
mov
al,Mh
out
dx,al
;Set Second or Minute :
mov
dx,2Eh
mov
al,0F5h
out
dx,al
mov
dx,2Fh
mov
al,Nh
out
dx,al
Note:
If N=71h, the time base is set to second.
M = time value
00: Time-out disable
01: Time-out occurs after 1 second
02: Time-out occurs after 2 seconds
03: Time-out occurs after 3 seconds
.
.
FFh: Time-out occurs after 255 seconds
86
;M=00h,01h,...FFh (hex),Value=0 to 255
Note
;(see
below)
;N=71h or 79h(see
Note
below)
Watchdog Timer
