The following figures show the limitation of an add-in card in different configuration.
IPC962-511/IPC962-512
No. Description
1
Slot 1: PCIe x 16
2
Slot 2: PCIe x4 or PCI
Note: Please note that below dimension is the maximum lengt h for add-on
card with I/O bracket.
Note: Considering heat dissipation potential, a space of 20mm must be left
between add-on card and system.
Hardware Installation
IPC962/IPC964 Series User's Manual
No. Description
3
Power connector of AX96205 or AX96206 or
AX96207(riser)
4
Internal fan module
45
