IPC962/IPC964 Series User's Manual
2.5
Installing the WIFI Module
The IPC962-511, IPC962-512 and IPC964-512 come with a Mini card slot and an USB
connector for users to install a wireless LAN card. Please refer to the following
instructions and illustrationfor the installation of the wireless LAN.
Installing the WIFI Module via Mini card
Step 1
Turn off the system.
Step 2
Disconnect the power connector.
Step 3
Loosen screws to remove the Heatsink cover from the chassis.
Step 4
Insert the wireless LAN card to slot. Push it down firmly. Then screw tightly
the card to the mainboard
50
→
→
Hardware Installation
