IPC962/IPC964 Series User's Manual
Installing the WIFI Module via USB
Step 1 Turn off the system.
Step 2 Disconnect the power connector.
Step 3 Loosen screws to remove the Heatsink cover from the chassis.
Step 4 Remove the antenna plug from the top of back cover, and then install the
antenna on the antenna connector
Step 5 Unscrew the thumbscrew and separating the cover from the expansion box
52
→
Hardware Installation
