replacing switches with AuroRa
Write down how many existing switches control the lights
you selected as 1–5 on your master control.
All On
Master Control
1
For lights controlled by one switch, use instructions
on pages 8 and 9.
2
For lights controlled by two switches, use instructions
on pages 10 and 11.
3
For lights controlled by three or more switches, use instructions
on pages 12 and 13.
Need help? Contact Lutron Technical Support 24/7: 800.523.9466
Rooms
Your locations:
Entry
1*:
Switch
Kitchen
Foyer
2*:
Switch
Grge Ext
3:
Dimmer
Family
4:
Dimmer
All Off
5:
Dimmer
* AuroRa
Switches require
®
neutral wire at chosen location.
dimmers/switches
®
Number of existing switches:
✓ Helpful Hint:
This circuit is called
a single-pole circuit.
Typical location:
Porch light
Bedroom light
✓ Helpful Hint:
This circuit is called
a three-way circuit.
Typical location:
Hallway light
Kitchen light
✓ Helpful Hint:
This circuit is called
a four-way circuit.
Typical location:
Stairwell light
|
