Lutron
RadioRA
2
®
®
Integration Guide
Luxor
®
Controllers with ZD Technology
®
and ZDC Technology
®
LUXOR
Lighting Accessories by Hunter Industries

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RadioRA 2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Lutron Electronics RadioRA 2

Summary of Contents for Lutron Electronics RadioRA 2

  • Page 1 Lutron RadioRA ® ® Integration Guide Luxor ® Controllers with ZD Technology ® and ZDC Technology ® LUXOR Lighting Accessories by Hunter Industries...

  • Page 2: Table Of Contents

    Table of Contents System Requirements Getting Started Adding Devices Integration IDs Telnet Logins 10 Programming Keypads 12 Project Transfer LUXOR 13 Luxor Controller Configuration 15 Troubleshooting...

  • Page 3: System Requirements

    System Requirements Getting Started RadioRA 2 System Requirements 1. Open the RadioRA 2 project. Software: RadioRA 2 Essentials or 2. In the DESIGN tab, locate the Main Repeater RadioRA 2 Inclusive by pressing the "Find Main Repeater" button.

  • Page 4: Getting Started

    Getting Started 3. Set Main Repeater DHCP to "Disabled" and record the IP address. Note: The Main Repeater IP address will be added to the Luxor controller. 4. Press "Save Settings." 5. In the Design tab, press "+" to add a Room. Note: Names should correspond to areas (e.g., Backyard, Palms, etc.) being turned ON by the Luxor controller.

  • Page 5: Adding Devices

    Adding Devices Adding Devices Devices are used as placeholders for each Luxor controller Group. 1. In the recently assigned Room, press "+ click here to add a device location" and select RF Maestro Tabletop.
  • Page 6 Adding Devices 2. Enter "Luxor All Groups" in the Device Location 5. Enter "LuxorGroup1" in the Device Location field and Zone Name fields. and "Luxor1" in the Zone Name field. 3. Click "Done." Device Location = LuxorGroupX 4. Click "+ Click here to add a device location" and Zone Name = LuxorX select RF Maestro Tabletop.
  • Page 7 Adding Devices 6. Click "Done." 7. Continue adding RF Maestro Tabletop devices until the number of devices equals the number of Luxor groups. Note: "Luxor All Groups" device should now be listed in Available Devices.

  • Page 8: Integration Ids

    Integration IDs Integration IDs 1. From the Essentials software menu bar, click the Integration Settings tab. 2. Click the IDs tab. 3. Double-click Integration ID for "Luxor All Groups" device and enter 500. 4. Double-click "Integration ID" and enter 501 for the device named Luxor1.

  • Page 9: Telnet Logins

    Telnet Logins Telnet Logins 1. From the Essentials software menu bar, click the Integration Settings tab. 2. Click the Telnet Logins tab. 3. Click "+ Click here to create a new Telnet login." 4. Enter "hunter" in Username field. 5. Enter "4HHuunntteerr" in the Password field. Note: "Bad Login"...

  • Page 10: Programming Keypads

    Programming Keypads Programming Keypads 3. Select keypad button that will be used to turn on Luxor Groups. 1. Click Program from the menu bar and select a Keypad to operate Luxor Groups. 4. Set the desired dimming level (0-100%). 2. Select the room where Luxor Groups are located. Note: Fade Time remains set at 0.
  • Page 11 Programming Keypads 7. Repeat steps 1–6 for Keypads and buttons to be used on Luxor Groups. Note: Luxor Groups devices are only placeholders and do not need to be activated within the Essentials software.

  • Page 12: Project Transfer

    Project Transfer Project Transfer 1. Select the Transfer tab in menu bar and select Start Transfer. Note: Ignore all "Device not addressed" warnings. Luxor Group devices do not need to be activated since they are used as placeholders.

  • Page 13: Luxor Controller Configuration

    Luxor Controller Configuration Luxor Controller Configuration 1. From the Luxor home screen, select "Setup." 2. Select Wi-Fi (or LAN for hardwire connection).
  • Page 14 Luxor Controller Configuration 3. Verify the router connection. 4. Select "Lutron." 5. Enter the Lutron IP address. Note: The IP address can be found on the Main Repeater (refer to page 4). 6. Enter 500 in the "Integration ID Start #" field. Enable Lutron 7.

  • Page 15: Troubleshooting

    Troubleshooting Connection Error "Bad Login" Message If the Luxor controller fails to connect, verify The "Bad Login" error message occurs the Lutron IP address is correct. when the Lutron login username and password do not match "hunter" and "4HHuunntteerr" (refer to page 9). If changes are made, the project will need to be transferred again (refer to page 12).
  • Page 16 Lutron and RadioRA are trademarks of Lutron Electronics Co. Inc., registered in the U.S. and other countries. © 2019 Hunter Industries Inc. Hunter, all related logos, and all other trademarks are property of Hunter Industries, registered in the U.S. and other countries.
