Custom Settings for Maestro
Model Numbers
MS-OPS2
MS-OPS5M
MS-OPS6M2-DV
MS-OPS6M2N-DV
Overview
Maestro
Occupancy sensing switches have custom settings that can be adjusted to the user's preference. The
®
settings include Timeout, Sensor Mode, and Advanced Settings (see the Custom Settings section for descriptions of
these settings).
General Instructions
Setting options vary depending on model number. Use the model number to identify which options are available and
then follow the instructions under each Custom Settings table.
Read all instructions before proceeding.
1. Press and hold the button(s) indicated in the picture below.
2. The lens will flash once at each setting; it will always start at setting 1.
3. The setting will be saved after releasing the button(s).
MS-VPS2
MS-VPS5M
MS-VPS6M2-DV
MS-VPS6M2N-DV
On/Off Button
Auxiliary Button
Lens
Occupancy Sensing Switches
®
1
Application Note #461
Technical Support — 800.523.9466
Revision B
August 2012
Advertisement
Related Manuals for Lutron Electronics Maestro MS-OPS2
Summary of Contents for Lutron Electronics Maestro MS-OPS2
- Page 1 Application Note #461 Revision B August 2012 Custom Settings for Maestro Occupancy Sensing Switches ® Model Numbers MS-OPS2 MS-VPS2 MS-OPS5M MS-VPS5M MS-OPS6M2-DV MS-VPS6M2-DV MS-OPS6M2N-DV MS-VPS6M2N-DV Overview Maestro Occupancy sensing switches have custom settings that can be adjusted to the user’s preference. The ®...
- Page 2 Application Note #461 Custom Settings Select your preferred settings from the instructions on the following pages before proceeding; default settings are shown in bold. Note: User is required to remove the wallplate in order to gain access to the Auxiliary button. Timeout • Timeout is the delay until light turns off after a room is vacated.
- Page 3 Application Note #461 Sensor Mode • Auto-On Daylight Sensing is the mode in which the light turns on only if natural light in the room is low. If the switch turns on when there is enough natural light, or if the switch does not turn on when there is not enough natural light, press the On/Off button within 5 seconds of entering the room.
- Page 4 Example 3: Changing to Low Sensitivity 1. Press and hold On/Off and Auxiliary buttons simultaneously. 2. Release both buttons after the lens flashes for the first time. Maestro is a registered trademark of Lutron Electronics Co., Inc. Lutron Contact Numbers WORLD HEADQUARTERS...
