Lutron Electronics AuroRa AR-ENT-2S3D Series Package Installation Manual page 10

lights controlled by two switches
1
Turn power off at circuit
breaker or remove fuse
2
Remove wallplate
Traditional
3
Unscrew existing switch and
pull it forward out of the wall
(do not disconnect wires yet)
4
Uninstall switch
Figure 4A
2
1
3
4 (ground wire)
|
Lutron 10 Need help? Contact Lutron Technical Support 24/7: 800.523.9466
OR
Designer
NOTE:
You only need to replace one of the two switches controlling the light
with an AuroRa
Once switch is pulled out, you should see one of the following:
A. Three insulated wires each
attached to a screw. One
ground wire (green or bare)
attached to a screw.
To uninstall switch, refer to
step 4 Figure 4A.
Figure 4B
Neutral
4 (ground wire)
To pull out wires 1, 2, and 3, refer
to page 8 step 4B for instructions.
dimmer/switch.
®
B. Three insulated wires inserted
A. Tag the wire attached to
1
B. Disconnect the wires from
2
3
WARNING
To avoid fire, shock or
death, turn power off
at corresponding circuit
breaker or remove fuse.
✓ Helpful Hint:
Save your wallplate and screws.
✓ Helpful Hint:
For wiring diagram for lights
controlled by two switches see
step 3B on page 21.
into back of existing switch.
One ground wire attached to
a screw.
To uninstall switch, refer to
step 4 Figure 4B.
the different colored screw.
This screw is usually labeled
COMMON.
the switch.
NOTE:
If intending to install an AuroRa
switch in this location, ensure
neutral is available before
disconnecting/uninstalling switch.
