4K@30HZ HDMI
EXTENDER WITH POE
• Do not mix up the HDMI EXTENDER sender and HDMI EXTENDER
receiver, and the IR blaster and IR receiver.
• Support and compliant with IEEE802.3af international standard
switcher and other POE power supply devices. The maximal
wattage of the transmitter or receiver is 10w only.
• The extender supports external 5V power supply for alternative.
Please do not connect POE power supply and 5V power supply at
the same time, choose each one would work.
INTRODUCTION
HDMI Extender, adopting a new high-definition digital transmission
technology, extends your HDMI video/audio with resolution of
4Kx2K 30Hz up to 120m via single network cable. Supports IR signal
transmission, to control media playback of the signal source device
at the display location. Supports POE.

PACKAGE CONTENTS

• HDMI EXTENDER sender TX x 1pc
• HDMI EXTENDER receiver RX x 1pc
• User manual x 1pc
• IR Blaster extension cable x 1pc
• IR receiver extension cable x 1pc
Note: above accessories are contented in the regular package
for the kit with transmitter and receiver. If buy HDMI Extender TX
or HDMI Extender RX separately, the package contents would
be different.

INSTALLATION REQUIREMENTS

1. HDMI source device (computer graphics card, DVD, PS3, HD
monitoring equipment, etc..)
2. HDMI display device like SDTV, HDTV, projector with HDMI port.
3. Network cables: UTP/STP Cat5e/6 networking cables, which
following the standard of EIA568B
Transmission length: CAT5E100m/CAT6 120m
4. POE powered device: Support and compliant with IEEE802.3af
international standard switcher and other POE power supply
devices. The maximal wattage of the transmitter or receiver is 10w
only.
