Microcom 438TM Operator's Manual page 83

Chapter 5
5.2.1.3 Software Switch #3
^AB ^D COMMAND
XX 23 Change SW3: Software Switch #3
^AB12345678 (each bit is represented by a numeric position number)
Position:
1 Extended ASCII: Controls whether characters over HEX 7F will be
processed.
2 INPUT 1 Active State: A setting of 1 (active LOW) will report the
>INPUT 1< message if no reflection is detected. A setting of 0 (active
HIGH) will report the >INPUT 1< message if a reflection is detected
(detecting media).
3 Response After Print: If enabled, an enquiry response will be sent
through the communications after every print automatically.
4 INPUT 2 Active State: A setting of 1 (active LOW) will report the
>INPUT 2< message if no reflection is detected. A setting of 0 (active
HIGH) will report the >INPUT 2< message if a reflection is detected
(detecting media).
5 Accept "|" for Ctrl: Sets whether the "pipe" character will be
interpreted the same as the "Ctrl" key. The "pipe" character is the
<SHIFT> + \ key.
6 Accept "^" for Ctrl: Sets whether the "caret" character will be
interpreted the same as the "Ctrl" key. The "caret" character is the
<SHIFT> + 6 key.
438TM Operator's Manual - 880049-0113
001 = ROM or Saved Format File 1
010 = ROM or Saved Format File 2
011 = ROM or Saved Format File 3
100 = ROM or Saved Format File 4
101 = ROM or Saved Format File 5
110 = Rom or Saved Format File 6
111 = ROM of Saved Format File 7
1 = Don't process input characters greater than 7F
0 = Process input characters greater than 7F
1 = Send >INPUT 1< report when not detecting
0 = Send >INPUT 1< report when detecting
1 = Enable
0 = Disable
1 = Send >INPUT 2< report when not detecting
0 = Send >INPUT 2< report when detecting
1 = Disable
0 = Enable (<|> key functions as <Ctrl> key)
1 = Disable
Printer Commands
5-15
