Bar Codes
Valid values for parameters
Type of GS1 Databar barcode:
0 = Omni-directional
1 = Truncated
2 = Stacked
3 = Stacked Omni-directional
4 = Limited
5 = Expanded
XY Multiplier:
Specifies the multiplier used to alter the XY size of the barcode. The range is 1 to
600 with 1 being the default.
reserved:
reserved:
reserved:
Separator Height:
MULTIPLIER < = Separator Height < = 2 * MULTIPLIER.
Specifies the vertical separation between the linear data and the 2D data. The
separator height is subtracted from the overall Height listed in the 1
Data:
Always 13 digits for the linear data unless using GS1 Databar Expanded which can
be up to 74 numeric or 41 alphabetic characters.
The "pipe" character (|) is used to separate the linear data from the 2D data.
^D114<CR> <------------------------- Here comes GS1 Databar data
0<CR>
50<CR>
0<CR>
0<CR>
0<CR>
3<CR>
0012345612345 <-------------------- 13 digits of data
^D57<CR>
2,1280,609,,25,6,0,1,395<CR>
1,190,300,1,35<CR> <---------------TCI=35 (GS1 Databar barcode)
2,190,200,11,1,5<CR>
^D56<CR>
^D2<CR>
x
^D3<CR>
Figure 8-7
8-6
<------------------------- Use –Omni-directional symbol
<------------------------- Height equals 50 dots
<------------------------- Reserved
<------------------------- Reserved
<------------------------- Reserved
<------------------------- Set vertical separator = 3
<------------------------- START of Label FORMAT
<---------END of Label FORMAT
<--------- START of Text String
<--------- any character will do... this is just a placeholder
<--------- PRINT command
GS1 Databar Sample Label FORMAT
438TM Operator's Manual - 880049-0113
Chapter 8
st
element.
