Table 4-7 Fo & Fj Character Starting Positions - Microcom 438TM Operator's Manual

Chapter 4
4.6.7 FO (Field Orientation)
TSN, XB, YB, CC, TCI, CGN,
This parameter defines the rotation of the format field on the label. The point of rotation is
determined from the Field Justification parameter.
0
1
2
3
4.6.8 FJ
TSN, XB, YB, CC, TCI, CGN, FO,
This parameter defines the justification of the format field on the label.
0
1
2
3
4
5
Table shows how to obtain the proper character placement or starting positions relative to
the format field's orientations and justifications.
ROTATION
0 & 180 Degrees
90 & 270 Degrees
Table 4-7
4.6.9 CMX (Character Multiplier X Direction)
TSN, XB, YB, CC, TCI, CGN, FO, FJ,
The CMX parameter multiplies each character in the X direction. The valid range is 1 to
65536. For bar codes with a FO of 0 & 180 degree rotation, the CMX would be the
multiplier while the CMY would be the actual height in thermal dots. For bar codes with a
FO of 90 & 270 degree rotation, the CMX would be the actual height in thermal dots while
the CMY parameter would be the multiplier.
438TM Operator's Manual - 880049-0113
FO
, FJ, CMX, CMY, CS, TSP,,, AN
0 degrees (normal rotation)
180 degrees (upside-down rotation)
90 degrees (left rotation)
270 degrees (right rotation)
(Field Justification)
FJ
Left Justified above the base-line
Right Justified above the base-line
Left Justified below the base-line
Right Justified below the base-line
Centered above the base-line
Centered below the base-line
FIELD ORIENTATION and JUSTIFICATION
0 – Left justified above the base-line
1 – Right justified above the base-line
2 – Left justified below the base-line
3 – Right justified below the base-line
4 – Centered above the base-line
5 – Centered below the base-line
0 – Left justified above the base-line
1 – Right justified above the base-line
2 – Left justified below the base-line
3 – Right justified below the base-line
4 – Centered on the Y axis, right of X coordinate
5 – Centered on the Y axis, left of the X coordinate
FO & FJ Character Starting Positions
Designing Labels with LDS
, CMX, CMY, CS, TSP,,, AN
CMX
, CMY, CS, TSP,,, AN
