Chapter 10
10.5 Replacing the Drive Roller
Over time, the platen may harden and cause print issues and need to be replaced. The
printer is equipped with an easy replaceable drive roller assembly.
1. Slide the black latches towards the center to release the printhead assembly and
then rotate to the open position.
438TM Operator's Manual - 880049-0113

Figure 10-5 Cleaning the Print Head

Figure 10-6 Releasing the Print Mechanism

Printer Maintenance
The printhead dot row
should be cleaned to
remove any
contaminates that may
impact print quality.
10-5
