Chapter 8
Edifact Encoding Scheme
X12 encoding scheme includes 63 ASCII values (values from 32 to 94) plus an Unlatch
character (binary 011111) to return to ASCII encoding. Edifact encoding encodes four data
characters in three codewords.
Codeword
1 - 128
129
130 - 229
230
231
232
233
234
235
236
237
239
241
Barcode ID
The printer is able to print two different unique Data Matrix barcodes per format and this
parameter is used to select which formatting data is being used. The valid parameters are a
0 or a 1. To printer the proper barcode, the CGN field must also reflect a 0 or 1 to match the
Barcode ID field. The CGN default is a 0 so if only one barcode is present and the Barcode
ID is a 0, nothing has to be entered as the CGN.
Data
Data to be converted to 2D Data Matrix Barcode, maximum number of characters supported
in the printer implementation is 1000.
438TM Operator's Manual - 880049-0113
Data and/or Function
ASCII data (ASCII value +1)
Pad Character
2 digit data 00 – 99 (Numeric Value + 130)
Latch to C40 Encoding Scheme
Latch to Base256 Encoding Scheme
Structured Append
Reader Programming
Upper Shift (shift to Extended ASCII)
Latch to Text Encoding Scheme
Table 8-6 ASCII Codeword Values
FNC1
05 Macro
06 Macro
ECI Character
