Chapter 3 Getting Started
Insert media
between the
guides until
resistance is felt
Slide the Thumbscrew to
adjust the guides so that the
edge of the media rests
against the walls of the green
media guides.
Figure 3-6 Loading Media
3.10 Print Button and Status Indicator Light
The Print Button and the Status Indicator Light are used to identify and perform many
functions. This section provides a description to familiarize you with the basic function of
the Print Button and the Status Indicator Light.
Status Light
Print
Button
Figure 3-7 Print Button and Status Indicator Light
