Inspur NF5280M5 User Manual page 90

Table 8-30 IIO Configuration Interface Instruction Table
Interface Parameters
SocketN Configuration
Intel VT for Directed I/O (VT-d)
Intel VMD Technology
Intel AIC Rtimer/AIC SSD Technology
(Non-VMD)
PCIe Hot Plug
PCI-E ASPM Support (Global)
PCIe Max Read Request Size
8.2.4.6 Advanced Power Management Configuration
Advanced Power Management Configuration interface is used to set the options related
with the CPU power management.
84
Function Description
Socket N configuration submenu, used to set the Link
speed, Max Payload Size and ASPM of the CPU0's PCIE
device, and to display the link status, maximum link
and current link speed of the PCIE port.
Intel VT-d settings submenu, Intel VT-d on-off settings ----
Intel VMD settings submenu, VMD on-off settings of
each PStack of each CPU.
Intel AIC Retimer/AIC SSD settings submenu, AIC Retimer/
AIC SSD on-off settings of each PStack of each CPU.
PCIe hot plug on-off settings. Options include:
Enabled
Disabled
PCIE ASPM support on-off settings. Options include:
Disabled
Per-Port
L1 Only
PCIe max read request size settings. Options include:
Auto
128B
256B
512B
1024B
2048B
4096B
Figure 8-56
Default Value
----
----
----
Enabled
Per-Port
Auto
