Inspur NF5280M5 User Manual page 144

9.11.1 BIOS Post Code (Port 80h)
BIOS sends Post code to IO port 80h. If there are any errors during power on, the last post
code is on port 80h. BMC is able to trace post code via port 80h to figure out the cause of
issue happened.
9.11.2 Screen Capture
BMC will record monitor screen after server power reset or power off. BMC also supports
BSOD (Blue Screen of Death) screen capturing, server OS should be Windows 2012R2 and
above.
138
Figure 9-34 BIOS Post Code
Figure 9-35 Screen Capture
