4.9 Remove the Air Baffle
CAUTION:
For proper cooling, do not operate the server without the access panel, air
baffle, or fan installed. If the server supports hot-plug components, minimize the amount of
time the access panel is open.
1.
Power down the server.
2.
Extend or remove the server from the rack.
3.
Remove the access panel.
4.
Remove the air baffle.
4.10 Remove the TPM
1.
Power down the server.
2.
Extend the server from the rack.
3.
Remove the access panel.
4.
Remove the air baffle.
5.
Remove the TPM.
Figure 4-10
Figure 4-11
Operations
23
