Install The Pcie Riser Cage - Inspur NF5280M5 User Manual

2. Extend the server from the rack.
3. Remove the access panel.
4. Remove the PCIE riser cage.

4.8 Install the PCIE Riser Cage

1. Power down the server.
2. Extend the server from the rack.
3. Remove the access panel.
4. Install the PCIE riser cage.
5. Install the access panel.
6. Install the server into the rack.
7. Power up the server.
Note: The riser card types supported by the PCIE riser cage are shown as follows:
X8x2 riser card
●
Figure 4-5
Figure 4-6
Operations
