the correct one.
9.23.1.2 Dual image
Dual image means BMC supporting two images in flash, when active image cannot boot,
BMC will try another image to boot.
9.23.1.3 WEB Update
BMC firmware update is supported via the Management Web GUI.
● Support hardware watchdog, please refer to "Hardware watchdog" in section "BMC Self
Recovery".
When updating BMC firmware, users can specify which image to update.
● Image-1
● Image-2
● Inactive image
● Both images (Default)
Configuration can be preserved separately. Please refer to section "Restore Factory
Defaults".
Note: The firmware upgrade process is a crucial operation. Make sure that the chances of a
power or connectivity loss are minimal when performing this operation.
Once you enter into Update Mode and choose to cancel the firmware flash operation, BMC
must be reset. This means that you must close the Internet browser and log back onto the
BMC before you can perform any other types of operations.
It defaults to boot the higher version of the two images. You can change the value from the
Web GUI.
Step 1
Go to "Administration->Dual Image Update" page, and select image to update. It defaults
to Both Images, which means both image will be updated. If configuration should be
preserved, click "Enter Preserve Configuration" to select items that need to be preserved.
Click "Enter Update Mode" to go to update page.
