2.2 Features and Specifications

Table 2-1
Processor
Processor Type
Socket
Chipset
Chipset Type
Memory
Memory Type
Memory Slot Qty.
Total Memory Capacity
I/O
USB
VGA
Serial Interface
UID
Display
Controller Type
SAS Backplane
SAS3.0 Backplane
NIC
NIC Controller
Management
Management Chip
PCI Expansion Slot
Drive
Drive Type
Two Skylake or Cascade Lake Intel® Xeon® scalable processors (supports up to
two 205W processors)
2
C622, C624
RDIMM, LRDIMM, NVDIMM, Apache Pass
24
Supports up to 3.0TB (128GB per memory module)
2 rear USB 3.0 ports, 2 built-in USB 3.0 ports, and 2 front USB ports
1 front VGA port
1 rear VGA port
1 built-in serial interface
2 UID LEDs and buttons (1 front and 1 rear)
Integrated in the Aspeed2500 chip, supports up to 1280*1024 resolution
Supports hot-plug SAS/SATA/SSD/NVME drive
The motherboard supports OCP/PCIE cards
It integrates 1 independent 1000Mbps network interface, special for IPMI
remote management
• Onboard: 2 PCI Express 3.0 ×24 slots + 1 PCI Express 3.0 ×24 slot (16 lane),
used to support PCI-E Riser card
• The Riser card supports horizontal-inserted and full-height cards
• Riser slot1 (CPU0 out): 1 Riser card, supporting 3 PCI Express 3.0 ×8 slots, or 1
PCI Express 3.0 x16 slot + 1 PCI Express 3.0 x8 slot
Riser slot2 (CPU0/1 out): 1 Riser card, supporting 3 PCI Express 3.0 ×8 slots,
or 1 PCI Express 3.0 x16 slot + 1 PCI Express 3.0 x8 slot
Riser slot3 (CPU1 out): 1 Riser card, supporting 2 PCI Express 3.0 ×8 slots, or
1 PCI Express 3.0 x16 slot
• Onboard: 1 Type A/C slot (for supporting OCP/PHY card)
2.5"/3.5" SAS/SATA/SSD/NVME drive (The machine you purchased shall prevail)
Product Specifications
