Analog-to-digital converter

Table of Contents

Figure 1. Evaluation Board

Features

SPI interface for setup and control

External, on-board oscillator

On-board LDO regulator, needing a single external 6V, 2A dc supply

ADC VREF configurable for ADC-internal reference, on-board reference, off-board reference

VisualAnalog® and SPIController software interfaces

Helpful Documents

AD9656

data sheet

High speed ADC FIFO evaluation kit (HSC-ADC-EVALEZ)

HSC-ADC-EVALEZ Wiki Guide

AN-905 Application

AN-878 Application

AN-877 Application

AN-835 Application

Connection—AD9656EBZ

http://wiki.analog.com/resources/eval/hsc-adc-evald

Note, VisualAnalog Converter Evaluation Tool Version 1.0 User Manual

Note, High Speed ADC SPI Control Software

Note, Interfacing to High Speed ADCs via SPI

Note, Understanding ADC Testing and Evaluation

Rev 20 Feb 2014 17:53 | Page 2

(on Left) and

HSC-ADC-EVALEZ

(on Right)
