Design and Integration Files

Schematics, layout files, bill of materials

Equipment Needed

Analog signal source(s) and antialiasing filter(s)
Sample clock source (if not using the on-board crystal oscillator)
Switching power supply (6.0V, 2.5A) for AD9656EBZ
Switching power supply (12V, 3,3A) for HSC-ADC-EVALEZ
PC running Windows®
USB 2.0 port
AD9656EBZ board
HSC-ADC-EVALEZ FPGA-based data capture kit

Getting Started

This section provides quick start procedures for using the
optional ADC settings are described.
Configuring the Board
Before using the software for testing, configure the evaluation board as follows:
1. Connect the evaluation board to the data capture board, as shown in Figure 1.
2. On the ADC evaluation board, confirm that the jumpers are installed as shown in Figure 2.
3. The AD9656EBZ can be powered in one of three ways. The default is to have the
obtain its power from the
jumper pin 1 to pin 2 on both P101 and P103 on the AD9656EBZ. The other power configurations
will be described in the Power Supplies section below.
4. Connect the 12V, 3.3A switching power supply to the
5. Connect the HSC-ADC-EVALEZ
6. On the ADC evaluation board, use a clean signal generator with low phase noise to provide an
input signal to the desired channel(s). Use a shielded, RG-58, 50Ω coaxial cable (optimally 1 m or
shorter) to connect the signal generator. For best results, use a narrow-band, band-pass filter with
50Ω terminations and an appropriate center frequency. (Analog Devices, Inc. uses TTE, Allen
Avionics, and K&L band-pass filters.)
<Coming Soon>
HSC-ADC-EVALEZ through the FMC connector. For this configuration,
board (P702) to the PC using a USB cable.
Rev 20 Feb 2014 17:53 | Page 3
AD9656EBZ board. Both the default and
HSC-ADC-EVALEZ board.
AD9656EBZ
