Helpful Documents - Analog Devices AD9681 Quick Start Manual

Figure 1. Evaluation Board
Features
SPI interface for setup and control
External, on-board oscillator
On-board LDO regulator or switching regulator, needing a single external 6V, 2A dc supply
ADC VREF configurable for ADC-internal reference, on-board reference, off-board reference
VisualAnalog® and SPIController software interfaces

Helpful Documents

AD9681 data sheet
High speed ADC FIFO evaluation kit (HSC-ADC-EVALDZ)
HSC-ADC-EVALDZ Wiki Guide
AN-905 Application Note, VisualAnalog Converter Evaluation Tool Version 1.0 User Manual
AN-878 Application Note, High Speed ADC SPI Control Software
AN-877 Application Note, Interfacing to High Speed ADCs via SPI
AN-835 Application Note, Understanding ADC Testing and Evaluation
Connection—AD9681-125EBZ
http://wiki.analog.com/resources/eval/hsc-adc-evald
Rev 13 Nov 2013 01:53 | Page 2
(on Left) and HSC-ADC-EVALDZ (on Right)
