Analog Devices ADSP-SC573 EZ-KIT Manual page 44

2
A B (
P10 and P11
Part Description
2-pin DuraClik
DuraClik cable assembly
Engine RPM (
Part Description
IDC 2x1 0.1"
Custom cable assembly
Microphone (
Part Description
IDC 2x1 0.1"
Custom cable assembly
Power Plug (
Part Description
2.1 mm power jack
12.0VDC@1.5A power supply
USB ( )
P23
Part Description
USB Micro-AB
USB Micro-B to Standard-A or Micro-A to Standard-A receptacle cable
Power Terminal Block (
®
ADSP-SC573 EZ-KIT Manual
