Regulator Disable ( Jp4 ); Current Measurement ( P17, P18, P20, P21 And P24 ); Hadc ( P25 ); Leds - Analog Devices ADSP-SC573 EZ-KIT Manual

Jumpers
Regulator Disable (
The Regulator disable jumper is used to allow either the CAN transceiver or the A
disable signal to the voltage regulator that powers the boards.
Table 3-12: Regulator Disable Jumper
Installed Jumper
1 and 2
2 and 3
Current Measurement (
The current measurement jumpers are used to measure the current draw of the
VDD_EXT and USB0_VBUS
draw, remove the jumper and measure the voltage across the precision resistor. The current can be calculated by
dividing the measured voltage by the 0.051 ohm resistor. For best results a differential probe should be used to meas-
ure the voltage across the resistor.
HADC ( )
P25
The HADC jumper is used to connect the HADC of the processor to various voltages on the board for monitoring.
Jumper
1 and 2
3 and 4
5 and 6
7 and 8

LEDs

This section describes the on-board LEDs. The LED Locations figure shows the LED locations.
3–14
