Safe Operation of MultiTest-x Systems

Appendix 2 gives guidance notes on the safe use of mains-powered test frames; you
should read this before proceeding any further. Within the European Union (EU), a
copy of this Appendix will, if appropriate, be supplied in a language appropriate to
your country by your local Mecmesin Agent.
Note: Although movement of the test stand crosshead can be stopped via software,
in an emergency pushing the [Emergency Stop] button on the left-hand side of the
control panel is the best method!

System Set-up and Operation

Connecting up

Connect the mains power lead to the three-pin power inlet connector at the rear of
the test stand (1), supply of power is controlled by the black rocker switch (2) above
the power inlet connector.
(2)
(1)
(3)
Mecmesin MultiTest-x Manual
3
(4)
(5)
