MultiTest
Load Measurement
Available loadcell ranges
Displacement
Crosshead travel**
Positional accuracy
MultiTest
Load Measurement
Available loadcell ranges
Displacement
Crosshead travel**
Positional accuracy
% of full scale(fs)
±0.1% fs
±0.2% fs
Common Specifications
Crosshead speed accuracy
Load measurement resolution
Operating temperature
Position control resolution
Humidity range
Compensation for system movement
Loadholding
Graphical representation
Output of test results to PC/Printer/Datalogger
Communication with PLC/Digital
Control Interface
Mecmesin reserves the right to alter equipment specifications without prior notice.
1- x
N 2 - 1000 (9 models)
0.2 - 100
kgf
lbf 0.45 - 225
mm 500
in 19.7
mm ±0.105/500
in ±0.0041/20
10- x
N 50 - 10,000 (8 models)
kgf 0.5 - 1000
lbf 11.25 - 2250
mm 960
in 37.8
mm ±0.050/800
in ±0.0020/31.2
N
2 - 2500N
5000 - 25000N
±1% of indicated speed
1:5000 or better
10-35 degrees Centigrade
±0.01mm (±0.0004")
Normal industry and laboratory conditions
Yes
Yes
External software
Yes, via RS232 serial port
Yes, via programmable digital ports
4 Inputs + 6 Outputs
18
Mecmesin MultiTest-x Manual
2.5- x
2 - 2500 (10 models) 2 - 5000 (11 models)
" 0.2 - 250
" 0.45 - 563
330
13
±0.070/300
±0.0028/11.8
25- x
50 - 25,000 (9 models)
" 0.5 - 2500
" 11.25 - 5625
950
37.4
±0.050/800
±0.0020/31.2
5- x
" 0.2 - 500
" 0.45 - 1125 "
675
26.6
±0.120/600
±0.0047/23.6
"
"
Options
Alternative speed ranges
Column gaiter
Extended columns
Extended throat depth
available upon request
"
E&OE
