PARTS LIST

ITEM QTY REFERENCE
1 1 PCB
2 1 C1
3 1 C2
4 1 C4
5 1 C5
6 1 INPUT
7 1 OUTPUT
8 1 P1
9 1 R1
10 1 R2
11 1 R3
12 2 R4, R8
13 1 R5
14 1 R6
15 1 R7
16 1 U1
17 1 VIOC
Note 1. These items are not stuffed (DNI).
DEMO MANUAL SCP-LT3094-EVALZ
PART DESCRIPTION
PCB
CAP CER 4.7UF 50V 10% X7R 1206
CAP CER 10UF 50V X5R 1206
CAP CER X7R
CAP MLCC 1206 (Note 1)
CONN-PCB MALE HEADER 3POS 2.54MM PITCH R/A GOLD
CONN FEMALE 3POS 2.54MM PITCH R/A GOLD
CONN-PCB 3POS HEADER WIRE TO BRD WAFER ASSY STRAIGHT
2MM PITCH (Note 1)
RES PRECISION THICK FILM CHIP
RES PRECISION THICK FILM CHIP
RES PRECISION THICK FILM CHIP
RES THICK FILM 0805 (Note 1)
RES STANDARD THICK FILM CHIP , FOR AUTOMOTIVE
RES PRECISION THICK FILM CHIP
RES PRECISION THICK FILM CHIP
IC-LIN -20V, 0.5A ULTRALOW NOISE, ULTRA HIGH PSSR
NEGATIVE LINEAR REGULATOR
CONN-PCB MALE HEADER 2POS 2.54MM PITCH R/A GOLD
MANUFACTURER/PART NUMBER
ANALOG DEVICES SUPPLIED 08_051372b
SAMSUNG CL31B475KBHNNNE
SAMSUNG CL31A106MBHNNNE
KEMET C1206C475K3RACTU
N/A
SULLINS PBC03SBAN
SULLINS PPPC031LGBN-RC
MOLEX 53253-0370
PANASONIC ERJ-3EKF2003V
PANASONIC ERJ-6ENF1003V
PANASONIC ERJ-6ENF3322V
N/A
VISHAY CRCW0603453KFKEA
PANASONIC ERJ-3EKF4992V
PANASONIC ERJ-6ENF4991V
LINEAR TECHNOLOGY LT3094EDD#PBF
SULLINS PBC02SBAN
