2.2.5 Connecting the Strobe
1. Remove the mounting screw to remove the cover plate. See
2. Remove the hole plug and grommet. See
3. Slide the cover plate through the slot on the cable grommet. See
4. Install the mounting screw to secure the cover plate. See
Mounting Screw
Hole Plug &
Grommet
Cover Plate
STROBE
Operations Guide
Figure 2-14. Connecting the Strobe
(Part of RGB Strobe)
Cable
Grommet
Slot
to STROBE
Paging Amplifier
MIC IN
931156K
Figure
Figure
2-14.
Figure
Strobe Cable Kit
Mounting
Screw
Slot
011288 Auxiliary RGB Strobe Kit
Installing the SIP Paging Amplifier
SIP Paging Amplifier Setup
2-14.
Figure
2-14.
2-14.
Back Plate
J1
RGB Strobe
CyberData Corporation
18
