6.4.7 Using Bite Alignment Tools

When you have successfully completed the Bite Alignment for your patient, you can
use the Bite-Alignment tools to visually inspect the quality of the alignment scans.
The Bite-Alignment Tool menu is displayed below the 3D reconstructed image of the
bite alignment.
Occlusion Distance Map
To visually check the clearance
distance between the maxillary
and mandibular arch scans:
i. Click on the Occlusion Distance
Map icon in the Bite Alignment
Tool menu.
ii. Adjust the color map by dragging
the visual slider to the
desired value.
Open Jaws
You can use this tool to open the jaws after the
bite alignment, to better inspect your scans.
Swap Jaws
Allows the user to swap jaw scans (in case
lower was scanned instead of upper or vice
versa).
Page 43
