3. Scan the Maxillary Palatal area
Scan the PALATAL area from molar to molar, ensuring the
connection of the surfaces (overlap):
•
Scan with 45°angle to get part occlusal + part palate
•
Scan with 90°angle to get last part of palate
Processing Data
When the scan is complete:
i. Turn the scanner off using the Start/Stop
button on the handle of the scanner.
The EzScan software will process the
Maxillary scan data before moving on
to the next phase of the Scan
Workflow.
If scanning both arches:
ii. Select the Mandibular arch next in
the Scan Workflow Menu.

6.4.2 Scanning the Mandibular Arch

Repeat the same scanning strategy as above for the Mandibular arch.
Due to the specific environment of the mandibular arch, it is recommended you
follow the following scan path:
Recommended Mandibular Scan Path
When scanning the Mandibular arch, it is recommended you scan in the following
order:
