A-8 V.35 Cables For Ports 4–7 - Cabletron Systems Netlink FRX4000 Maintenance Manual

To FRX4000
AA
Physical DCE
(Female Connector)
Pin
A
B
C
D
E
F
H
P
R
S
T
U
V
W
X
Y
AA
Figure A-8 V.35 Cables for Ports 4–7
A-8
Cabletron part numbers:
DCE FRX-V35DCE-CAB
DTE FRX-V35DTE-CAB
C A
D B
(Male Connector)
Signal
FGnd
SGnd
RTS
CTS
DSR
DCD
DTR
SDa
RDa
SDb
RDb
TTa
RCa
TTb
RCb
TCa
TCb
FRX4000 Maintenance Guide, Rev 03
AA
A C
B D
Physical DTE
Pin Signal
A FGnd
B SGnd
C RTS
D CTS
E DSR
F DCD
H DTR
K LT
P SDa
R RDa
S SDb
T RDb
U TTa
V RCa
W TTb
X RCb
Y TCa
AA TCb
