Figure 3-5 Removing the FRX4000 Cover
4. Grasp the front of the top and lift the top up and off.
Testing Component Voltages
Be careful! These procedures are performed with
exposed live AC and DC power.
To make sure certain components are transmitting/receiving the
proper voltages, follow this procedure:
1. Remove the unit's cover as described on
2. Being careful to avoid contact with live components, reconnect
the power cable and switch the unit on.
3-4
page
3-3.
FRX4000 Maintenance Guide, Rev 03
