Removing the Chassis Cover
1. Make sure the power cable is disconnected from the rear of the
device.
2. Turn the unit over and remove the screw shown in the following
figure.
Figure 3-4 FRX4000, Bottom View
3. Turn the unit right side up. Grip the top and bottom of the unit
securely and pull the the top one to two inches forward, as
shown in the following figure.
Testing & Replacing Components
Remove Screw
3-3
