Port Status Disp lay (Page 1)
P Typ e PPS Conn # State
0 FR 62 4 Op erational
2 S NA 112 7 Op erational
4 S NA 110 3 Op erational
6 A SY 0 0 Lin k_disab le
F1: Login
Figure 2-1 Port Status Display
From this screen, you should be able to log into the
(Figure 2-2), which is the starting point for most configuration and
operation procedures.
2-2
Rmtid=local
P Type PPS C onn# State
1 FR 127 12 Operational
3 SN A 60 6 Operational
5 SN A 87 5 Operational
7 X25 88 4 Operational
Main Menu
FRX4000 Maintenance Guide, Rev 03
