2.3

Checklist for Tunnel connection

A connection between V-Tap and Apresa or PC software is needed to
get the recorded data automatically into a user accessible database.
The following checklist can be used to setup this Tunnel connection:
1) Install the Hardware.
2) Install Apresa or V-Archive PC
3) Open the Settings page
XXXX are the last 4 digits of the MAC address, found on the bottom.
It may take up to a minute after first connect, before this local name is known to the PC.
4) On that page, the IP address of the Apresa or the PC with V-Archive must be
entered as the
5) Any firewall must have a rule that makes it possible to receive from TCP port
2016, the default
During installation of V-Archive this port is automatically opened, if permitted by the PC.
6) The Tunnel connection is stable when the
The V-Tap must be shown with its MAC address in the status line of V-Archive.
7) For first tests, better turn off "Tunnel Data Encryption". Otherwise, be sure
that the Encryption password is the same in both V-Tap and Apresa or PC.
8) When data is stored during a call, the
9) To see if the PC receives something from the V-Tap, it is possible to make a
network trace for test purposes. In V-Archive, go to menu Actions and select
'Network trace', press Start, make a short call, wait 10 seconds, press Stop and
then Save. From the zip file 'tunneltrace.pcap' can be analyzed with
Wireshark.
The Apresa recorder has a similar option to make a network trace in menu
Tools, System.
10) The SD card in the V-Tap should contain ".WAV" files. This SD card can be
read by the V-Archive software in menu File and 'Import from V-Tap'.
V-Tap Analog 2 Manual EN v4.21 Sept 2021 © 2018-2021 Vidicode
Software
of the V-Tap in a browser,
"Tunnel Server Address".
"Tunnel Destination
and enable V-Tap connections.
http://vtapXXXX.local
Port".
GREEN LED is
BLUE LED blinks.
steady, not blinking!
