Vidicode V-Tap Manual page 31

Special Analog & Audio settings
".AS<num>"
".AH<num>"
".AA<num>"
".AI<num>"
".AT<num>"
".AN<num>"
".AF0/1"
".AR0/1"
".GD<num>"
".GF<num>"
".GH<num>"
".GV<num>"
".GI<num>"
".GA<num>"
".GB<num>"
".GR<num>"
".VP<num>"
".VD<num>"
".VO<num>"
".VL<num>"
".VR<num>"
".VI<num>"
".VA<num>"
".VB<num>"
".OH<num>"
".OV<num>"
".OP<num>"
Special Wi-Fi settings
".LAN"
".WF"
".WC<chan>"
".WR<pow>"
".WD"
".WN"
".WI<ip>"
".WH"
".WL"
".WT<secs>"
".WK<secs>"
".WUP"
".WZ0/1"
V-Tap Analog 2 Manual EN v4.21 Sept 2021 © 2018-2021 Vidicode
= Set Audio detect Sensitivity 0-255 per 10ms (default=15)
= Set Hook detect Sensitivity 0-255 per 10ms (default=10)
= Set Audio to output 0-3; bit0=A (left) , bit1=B (right)
= Set Input to output 0-3; bit0=A (left) , bit1=B (right)
= Set ALC Target level 0-15 per 1.5dB (default=11= -6dB).
= Set Noise Gate Threshold 0-31 per 1.5dB (default=28= -6dB)
= High Pass Filter 0=off or 1=on (default=off)
= Ring detect line on 0/1
= Gain for DTMF detect 0-7
= Gain for FSK detect 0-7
= Gain for Hook level detect 0-3
= Gain for Voice level detect 0-3
= Gain for Chan A+B inputs 0-3 (default=0=0dB per +10dB)
= Gain for Channel A input only (
= Gain for Channel B input only (
= Gain for Recorded file 0-255 (default=177= -9dB per +0.5dB)
= Volume for Playback 0-255
= Volume for Detect output 0 or 1 (default=1=0dB , 0=-6dB)
= Volume for Audio outputs 0-127 (def.=121=0dB per +1dB)
= Volume for Audio output A only ( ,,
= Volume for Audio output B only
= Volume for Chan A+B in2outs 0-7 (default=7=0dB per -3dB)
= Volume for Channel A in2out only ( ,,
= Volume for Channel B in2out only ( ,,
= Offset for Hook detect 0-2047
= Offset for Voice detect 0-2047
= Offset for Playback 0-65535
= Start with the LAN cable and fallback to Wi-Fi connection.
= Disable Fallback from Wi-Fi to LAN cable.
= Set Wi-Fi Channel ID; 1 till 13.
= Set Wi-Fi RF TX Power; 0 till 82 per 0.25 dBm.
= Set the DNS server for Wi-Fi the same as the LAN cable.
= Disable NTP from Wi-Fi.
= Set IP address for web server access, default 192.168.55.66
= Set DHCP range <ip>1 till <ip>9 when using .WI
= Disable the web login page after Wi-Fi connection.
= Set Timeout for the TCP web server (default 90).
= Keep-alive timer for the Wi-Fi Tunnel connection (def 60).
= Try to update the Wi-Fi module.
= Disable/Enable Wi-Fi module during recording.
(default=3)
(default=3)
(default=0)
(default=0)
,, ,,
,, ,,
(default=255= 0dB per +0.5dB)
,,
( ,, ,,
,,
,,
(default=508)
(default=0)
(default=32767)
)
)
,, )
,, )
,, )
,, )
31
