Quick Guide for the V-Tap Analog 2

The V-Tap Analog 2 is a device that can record the audio from an analog

telephone line or any telephone that works with a handset. Additionally, there

is a 3.5 mm stereo input jack that enables recording from other audio sources,

such as microphones or radio's. The captured data is stored onto an SD card and

can optionally be sent to an external server (an Apresa recorder or the Call

Recorder VoIP software running on the PC).

NOTE:

When no analog line is connected or when no SD card is inserted, the Red LED starts

flashing on first power on with default settings, to indicate an error situation.

NOTE:

The SD card must be formatted with the FAT32 file system. Cards above 32 GB (up to 2 TB)

are not tested and must be formatted as FAT32 first, before inserting them into the V-Tap.

• V-Tap Analog unit

• USB adapter

• USB cable

• Curled Telephone cable

• SD card

• CD with manual and Call Recorder VoIP software for the PC

• 1 year Support & Update license

• This Quick Guide

V2.1

BOX CONTENT

Table of Contents

Do you have a question about the V-Tap Analog 2 and is the answer not in the manual?

Page 1 Quick Guide for the V-Tap Analog 2 The V-Tap Analog 2 is a device that can record the audio from an analog telephone line or any telephone that works with a handset. Additionally, there is a 3.5 mm stereo input jack that enables recording from other audio sources, such as microphones or radio’s.
Page 2 Quick Guide for the V-Tap Analog 2 HARDWARE INSTALLATION – TWO WAYS TO CONNECT TO A PHONE SYSTEM 1. On an analog line, in between the wall and the phone: 2. In between the handset and the phone: NOTE1: USB must be connected for power supply.
Page 3: Software Installation
Quick Guide for the V-Tap Analog 2 PC REQUIREMENTS FOR THE CALL RECORDER VOIP SOFTWARE Windows Vista/7/8/10 , Intel Pentium >2GHz , 4GByte RAM , >100 MB free disk space. CALL RECORDER VOIP SOFTWARE INSTALLATION 1. Connect the V-Tap Analog to a free USB port on your PC.
