Quick Guide for the V-Tap Analog 2

The V-Tap Analog 2 is a device that can record the audio from an analog telephone line

or any telephone that works with a handset. Additionally, there is a 3.5 mm stereo

input jack that enables recording from other audio sources, such as microphones or

radio's. The recorded calls are stored onto an SD card and can optionally be sent to an

external server, which can be a

on a PC.

NOTE1: The USB power supply needs to deliver 500 mA current, else the system does not start.

NOTE2: When no analog line is connected or when no SD card is inserted, the Red LED starts

flashing on first power on with default settings, to indicate an error situation.

NOTE3: The SD card must be formatted with the FAT32 file system. Cards above 32 GB (up to 2 TB)

are not tested and must be formatted as FAT32 first, before inserting them into the V-Tap.

• V-Tap Analog 2 unit

• USB adapter

• USB cable

• Telephone cable & Handset cable

• SD card

• 1 year Support & Update license

• This Quick Guide

• Manual:

https://www.vidicode.com/download/v-tap-analog-2-manual-en/

• V-Archive PC software:

v2.9

Call Recorder Apresa

BOX CONTENT & DOWNLOADS

https://www.vidicode.com/download/v-archive/

or the

V-Archive software

running

1/4

Table of Contents

Need help?

Do you have a question about the V-Tap Analog 2 and is the answer not in the manual?

Page 1 Quick Guide for the V-Tap Analog 2 The V-Tap Analog 2 is a device that can record the audio from an analog telephone line or any telephone that works with a handset. Additionally, there is a 3.5 mm stereo input jack that enables recording from other audio sources, such as microphones or radio’s.
Page 2 Quick Guide for the V-Tap Analog 2 HARDWARE INSTALLATION – TWO WAYS TO CONNECT TO A PHONE SYSTEM 1. On an analog line, in between the wall and the phone: 2. In between the handset and the phone: NOTE1: USB must be connected for power supply and must deliver 500 mA.
Page 3 Quick Guide for the V-Tap Analog 2 PC REQUIREMENTS FOR THE V-ARCHIVE SOFTWARE Windows Vista/7/8/10 , Intel Pentium >2GHz , 4GByte RAM , >100 MB free disk space. V-ARCHIVE SOFTWARE INSTALLATION • In the case that no CD is supplied, you can download V-Archive from here: www.vidicode.com/download/v-archive/...
Page 4 Quick Guide for the V-Tap Analog 2 CHECKLIST FOR TUNNEL CONNECTION A connection between the V-Tap and the V-Archive PC software (or Apresa recorder) is needed to get the recorded data automatically into a user accessible database. The following checklist can be used to setup this Tunnel connection: 1) Install the Hardware (see page 2).
