2.3

Checklist for Tunnel connection

A connection between V-Mic and Apresa or PC software is needed to get
the recorded data automatically into a user accessible database.
The following checklist can be used to setup this Tunnel connection:
1) Install the Hardware, and note that, only during installation of V-Archive,
the V-Mic needs to be connected once with USB to the same PC.
2) Install Apresa or V-Archive PC
3) Get access to the V-Mic over the network by opening the settings page in a
browser. This can be done with a
4) On that page, the IP address of the Apresa or the PC with V-Archive must be
entered as the
Tunnel" must be enabled.
5) Any firewall must have a rule that makes it possible to receive from TCP port
2016, the default
be changed, when needed.
During installation of V-Archive this port is automatically opened, when this is
allowed by the PC.
6) To see if the PC receives something from the V-Mic, it is possible to make a
network trace for test purposes.
In V-Archive, go to menu Actions and select 'Network trace', press Start, make
a short recording by pressing the button twice, wait 20 seconds, press Stop
and then Save. From the zip file 'tunneltrace.pcap' can be analyzed with
Wireshark.
The Apresa recorder has a similar option to make a network trace in menu
Tools, System.
7) The SD card in the V-Mic should contain ".WAV" files. The SD card can be
read by the V-Archive software in menu File and 'Import from V-Tap'.
The WAV files can also be opened by explorer on a PC with audio playback.
V-Mic Manual EN v1.5 Juli 2020
Software
"External Storage IP
"External Storage TCP
and enable V-Tap connections.
network cable or with Wi-Fi.
Address" and the "External Storage via
Port". This tunnel port number can
© 2020 Vidicode 7
