Error Packets Ratio

Select "Statistics" then "Error Packets Ratio" to display the graphic
representation of the distribution of error types.
Item
Broadcast Packets
Multicast Packets
CRC Align Errors
Undersize Packets
Oversize Packets
Fragments
Jabbers
Collisions
Residuals
[Refresh]
Refresh Mode Select
Values are counted from the time the Control Table entry was created.
9033060
Description
Percentage of broadcast packet errors.
Percentage of multicast packets errors.
Percentage of CRC and alignment errors.
Percentage of undersize packets.
Percentage of oversize packets.
Percentage of fragments.
Percentage of jabbers.
Percentage of collisions.
Percentage of remaining error types.
Immediately refreshes the status.
The scroll-down window includes options for:
"autoRefresh" of the screen every 10 seconds, or
"manual" refresh by pressing the [Refresh] button.
Web-Based Management 77
