SNMP Configuration Menu

Use the SNMP Configuration Menu to display and modify parameters for
the Simple Network Management Protocol (SNMP). The Agent Module
monitors the hardware status of the hub (or connected stack), as well as
the traffic passing through the ports. A Network Management Station
(NMS) can access this information using third-party network management
software. Access rights to the management agent are controlled by
community strings. To communicate with the management agent, the
NMS must first submit a valid community string for authentication. The
options for configuring community strings and related trap functions are
described in Figure 3-6, Figure 3-7, and Figure 3-8 and their
accompanying tables
Use <TAB> or cursor keys to move, <SPACE> to toggle, <ENTER> to select
Selection
Transmit
Authentication Failure
Traps
SNMP Communities
SNMP Trap
Destinations
9033060
.
Figure 3-6. SNMP Configuration Menu
SNMP Configuration
==================
Transmit Authentication Failure Traps: YES
SNMP Communities ...
SNMP Trap Destinations ...
<APPLY>
Press <ENTER> to go to the SNMP Communities Screen
Description
Issue a trap message whenever authentication of an
SNMP request fails. The default is to issue traps to
specified IP trap managers.
Assigns SNMP access based on specified community
strings.
Specifies management stations that will receive
authentication failure messages or other trap
messages from the hub.
<OK> <CANCEL>
ELH100-12/24TX User Interface 35
