Hub Configuration

Select "Hub" then "Hub Configuration" to display hardware and firmware
configuration of the hub.
Item
Hub ID
Model
Hardware Version
Repeater Serial No.
System Version
POST Version
Agent Status
Agent Hardware
Version
Agent Serial No.
Agent MAC Address
Agent Baud rate
Switch Module
Number of Ports
9033060
Description
Hub identifier in stack.
The model number of this hub.
Version number of the hub hardware.
Serial number of this hub.
System firmware version.
Version number of the Agent Module's Power-on Self-test.
Indicates if an Agent Module is installed and active.
Hardware version number of the Agent Module.
Serial number of the Agent Module.
Physical address of the active Agent Module.
Rate at which data is sent between the Agent Module's serial
port and the connected device. The supported baud rate is
9600 bps.
Indicates if a switch/media module is installed.
Indicates whether this device has 12 or 24 repeater ports.
Web-Based Management 67
