Console Configuration Menu

The Console Configuration menu is used to configure the console
connected to the hub's serial port. The console parameters are described
in the following figure and table.
Automatic Logout Status:
Automatic Logout Delay Time:
Auto-Refresh Period:
Use <TAB> or cursor keys to move, <SPACE> to toggle, <ENTER> to select
Selection
Automatic Logout
Status
Automatic Logout
Delay Time
Auto-Refresh Period
9033060
Figure 3-17. Console Configuration Menu
Console Configuration
=====================
<APPLY>
Use the space bar to toggle automatic logout
Description
Enables/disables the logout function.
If no input is received from the attached device after this
interval (in minutes), the current session is closed.
Range: 0 - 99 minutes. Default is 10 minutes.
Specifies the interval at which statistics are read from the
hub.
Options: 30, 60, 120, 180, 300 seconds. Default is 30
seconds.
ON
10 Minutes
30 Seconds
<OK> <CANCEL>
ELH100-12/24TX User Interface 47
