System Information Menu

Use the System Information menu to display descriptive information
about the hub, or for quick system identification. Figure 3-4 shows and the
accompanying table describes the System Information menu
System Desc.: Cabletron ELH100 Dual Speed Hub
Sys. Obj. ID: 1.3.6.1.4.1.52.3.9.1.10.5
Sys. Up Time: 6213437 (0 day 17 hr 15 min 34 sec)
System Name:
Contact:
Location:
<Ctrl-F> to move forward a character, <Ctrl-B> to move back a character
Selection
System Description
System Object ID
Sys. Up Time
System Name*
Contact*
Location*
* Maximum string length is 255, but the screen only displays 44 characters. You
can use the arrow keys to browse the whole string.
9033060
Downloads new firmware to update the Agent Module via a
console interface.
Sets Administrator and Guest names and passwords used for
system access.
Sets console time-out and refresh period for displayed statistics.
Displays network performance for each hub in the stack.
Displays network performance for the selected port.
Figure 3-4. System Information Menu
System Information
==================
Cabletron Inc., 0021-516-435-6475
<APPLY>
Type the system name character string
Use <TAB> or cursor keys to move, <ENTER> to select,
Description
System hardware description.
Object identifier for the hub's network management subsystem
as defined in MIB II.
Time since the hub was powered on.
Name assigned to the hub system.
Contact person for the system.
Specifies the area or location where the system resides.
<OK> <CANCEL>
ELH100-12/24TX User Interface 31
.
