DEMO MANUAL SCP-5X1-EVALZ

PARTS LIST

ITEM QTY REFERENCE
1 1 PCB
2 5 C1, C2, C3, C4, C5
3 5 INPUT1, INPUT2,
INPUT3, INPUT4,
INPUT5
4 10 J1, J2, J3, J4, J5,
J6, J7, J8, J9, J10
5 5 LED1, LED2, LED3,
LED4, LED5
6 1 P6
7 5 R1, R2, R3, R4, R5
8 5 SMA1, SMA3,
SMA5, SMA7,
SMA9
9 5 SMA2, SMA4,
SMA6, SMA8,
SMA10
10 5 TP1, TP3, TP5,
TP7, TP9
11 5 TP2, TP4, TP6,
TP8, TP10
Note 1. These items are not stuffed (DNI).
4
PART DESCRIPTION
PCB
CAP MLCC 2220 (Note 1)
CONN MALE 3POS 2.54MM PITCH R/A
CONN-PCB BANANA JACK
LED BI-COLOR GREEN
CONN 6POS MALE SHROUDED, 2MM PITCH
RES THICK FILM 0805 (Note 1)
CONN-PCB STRAIGHT SMA PCB DIE CAST (Note 1)
CONN-PCB STRAIGHT SMA PCB DIE CAST
CONN-PCB TEST POINT RED
CONN-PCB TEST POINT BLACK
MANUFACTURER/PART NUMBER
ANALOG DEVICES 08_051790b
N/A
SULLINS PBC03SBAN
KEYSTONE ELECTRONICS 575-4
LITE-ON TECHNOLOGY LTST-C235KGKRKT
HIROSE ELECTRIC CO. DF3A-6P-2DSA
N/A
TE CONNECTIVITY LTD 5-1814832-1
TE CONNECTIVITY LTD 5-1814832-1
KEYSTONE ELECTRONICS 5010
KEYSTONE ELECTRONICS 5011
Rev. 0
