Table D-5. Onu-96 Narrowbandband Cabling/Hdsl2 Loop 1 Assignments - ADTRAN H2TU-C Installation And Maintenance Practice

Litespan H2TU-C Installation and Maintenance Practice

Table D-5. ONU-96 Narrowbandband Cabling/HDSL2 Loop 1 Assignments

Color Code
(Base/Ink)
Tip - Ring
710 or 3M
Wh/Bl - Bl/Wh 1 - 2
Wh/Or - Or/Wh 3 - 4
Wh/Gr - Gr/Wh 5 - 6
Wh/Br - Br/Wh 7 - 8
Wh/Sl - Sl/Wh 9 - 10
Rd/Bl - Bl/Rd 11 - 12
Rd/Or - Or/Rd 13 - 14
Rd/Gr - Gr/Rd 15 - 16
Rd/Br - Br/Rd 17 - 18
Rd/Sl - Sl/Rd 19 - 20
Bk/Bl - Bl/Bk 21 - 22
Bk/Or - Or/Bk 23 - 24
Bk/Gr - Gr/Bk 25 - 26
Bk/Br - Br/Bk 27 - 28
Bk/Sl - Sl/Bk 29 - 30
Yl/Bl - Bl/Yl 31 - 32
Yl/Or - Or/Yl 33 - 34
Yl/Gr - Gr/Yl 35 - 36
Yl/Br - Br/Yl 37 - 38
Yl/Sl - Sl/Yl 39 - 40
Vi/Bl - Bl/V 41 - 42
Vi/Or - Or/Vi 43 - 44
Vi/Gr - Gr/Vi 45 - 46
Vi/Br - Br/Vi 47 - 48
Vi/Sl - Sl/Vi 49 - 50
D-6
Pin # P1
(T - R)
AMP Slot
26 - 1 1
27 - 2
28 - 3
29 - 4
30 - 5 2
31 - 6
32 - 7
33 - 8
34 - 9 3
35 - 10
36 - 11
37 - 12
38 - 13 4
39 - 14
40 - 15
41 - 16
42 - 17 5
43 - 18
44 - 19
45 - 20
46 - 21 6
47 - 22
48 - 23
49 - 24
50 - 25 7
P2
Pair Slot Pair
1
8 29
5
9 33
9
10 37
13
11 41
17
12 45
21
13 49
25
P3 P4
Slot Pair Slot
20
14 53
21
15 57
22
16 61
23
17 65
24
18 69
N/C
19 73 N/C
N/C
N/C
61221002L1-5F
Pair
77
81
85
89
93
97
98
99
100
