CBA Wideband Cabling Details

LITESPAN SHELF CABLING PINOUTS

The tables in this appendix provide the cabling details for the Litespan CBA shelf.
• The first column identifies the color code of each pair.
• The second and third columns list the tip-ring pin numbers of either the 710 (or 3M) cable
or the AMP cable provided by the CBA.
• The even-numbered cable columns (J2, J4, and J6) list the Slot number/HDSL2
assignment to Loop 1.
• The corresponding Pair columns list the pairs in sequential order.
The following tables are available:
• "CBA Wideband Cabling/HDSL2 Loop 1 Assignments"
• "Odd CBA Narrowband Cabling (Last Pair Unassigned)/HDSL2 Loop 1 Assignments"
page D-3
• "Even CBA Narrowband Cabling (Last Pair Unassigned)/HDSL2 Loop 1 Assignments"
page D-4
• "ONU-96 Wideband Cabling/HDSL2 Loop 1 Assignments"
• "ONU-96 Narrowbandband Cabling/HDSL2 Loop 1 Assignments"
61221002L1-5F
Appendix D
on page D-2
on page D-5
on page D-6
on
on
D-1
